Key Features

• Universal Application – Suitable for adult, pediatric, and neonatal patients 👶👩‍⚕️👴

• 12.1″ TFT Color LCD – Clear, detailed display for quick, accurate readings 📊

• Comprehensive Monitoring – ECG, NIBP, SpO₂, Pulse Rate, Respiration, Temperature, with upgradable IBP 🌡️

• Multi-Channel Waveform – View up to 8 parameters simultaneously for a complete patient overview 📺

• 96-Hour Trend Data – Graphical & tabular history for effective diagnosis & follow-up 📈

• Customizable Display – Multi-screen format for efficient workflow 🖥️

• Robust Data Storage – Saves up to 500 NIBP measurements for quick recall 💾

• Uninterrupted Operation – AC/DC power with built-in rechargeable lithium battery 🔋

• Safety Alerts – Adjustable visual & audio alarms for abnormal readings 🔔

• Flexible Modes – Manual, Auto, and Stat modes for varied clinical needs ⚡

Specifications

ECG

• Lead Type: 5-lead or 12-lead selectable

• Heart Rate Range:

  • Adult: 15–300 bpm

  • Pediatric/Neonatal: 15–350 bpm 💓

• ST Detection & Arrhythmia Analysis

• Accuracy: ±1 bpm or ±1% (whichever is greater)

• Electrical Protection: Withstands 4000V AC/50Hz isolation

NIBP

• Range: Adult: 10–270 mmHg

• Resolution: 1 mmHg

• Accuracy: Mean ±5 mmHg, Std. Dev. ±8 mmHg

• Alarm for Systolic, Diastolic, and Mean pressure

Respiration

• Range:

  • Adult: 0–120 rpm

  • Pediatric/Neonatal: 0–150 rpm

• Apnea Alarm 🚨

SpO₂

• Range: 0–100%

• Accuracy: ±2% (70–100%)

• Adjustable alarm range

Pulse Rate

• Range: 10–270 bpm

• Accuracy: ±2 bpm

Temperature

• Range: 0–50°C

• Resolution: 0.2°C 🌡️

IBP (Optional Upgrade)

• Sensitivity: 5 mV/V/mmHg

• Pressure Range: -10 to 300 mmHg

Package Includes

• Flight 9000 Monitor

• Power connector

• Adult/Pediatric/Neonatal cuff + cable (as selected)

• ECG leads

• SpO₂ probe

• Temperature probe

• User manual
